Cycles++ documentation
Cycles++ is a multiplayer implementation of the Light Cycles game from Tron. In this implementation bots play against other bots.
The game is played on a grid, where each player controls a cycle that leaves a trail behind it. The goal is to make the other players crash into the walls or the trails left by the other cycles.
The bots communicate with the server with a simple protocol over TCP. The server sends the game state to the bots and the bots respond with their actions.
The networking code as well as graphics are based on the SFML library.
Installation
The server and clients are written in C++ and require a C++20 compiler. All dependencies can be installed using the provided conda environment:
conda env create -f environment.yml
conda activate cycles
Warning
There is a bug in the latest SFML package for linux (WSL in Windows included). Fixing it requires to manually create a missing symlink to libudev:
mamba install libudev
ln -s $CONDA_PREFIX/lib/libudev.so.1 $CONDA_PREFIX/lib/libudev.so.0
You might have to install the libudev package from conda.
Warning
If you are on Windows and using the WSL you must install the graphical drivers:
sudo apt install mesa-common-dev
To build the server and the example client, clone the repository and run the following commands from the root directory of the repository:
mkdir build
cd build
cmake ..
cmake --build .
The server and the example client will be built in the build/bin directory.
Usage
Both the server and the clients expect the environment variable CYCLES_PORT to be set to the port where the server will run.
To start the server, run the following command:
./build/bin/server <config_file>
config_file is the path to a yaml file containing some server options. The following is an example of a config file:
gameHeight: 1000
gameWidth: 1000
gameBannerHeight: 100
gridHeight: 100
gridWidth: 100
maxClients: 60
enablePostProcessing: false
The option enablePostProcessing is used to enable or disable the fancy graphic effects. If you are seeing weird graphical glitches you might want to disable the post processing. To start a client using the example bot, run the following command:
./build/bin/client <name>
name is the name of the bot. The bot will receive the game state from the server and will respond with its actions. The example client will move the cycle in a random-ish direction.
You might want to write your own bot.
Example launch script
The following script will start the server and some clients:
export CYCLES_PORT=50017
cat<<EOF> config.yaml
gameHeight: 1000
gameWidth: 1000
gameBannerHeight: 100
gridHeight: 100
gridWidth: 100
maxClients: 60
enablePostProcessing: false
EOF
./build/bin/server &
sleep 1
for i in {1..30}
do
./build/bin/client randomio$i &
done
